ofxPresetsManager

Overview

An openFrameworks add-on to handle presets of ofParameter's nested into single or multiple ofParameterGroup containers. Also powered with a nice GUI, many Helpers, and a complete user workflow.

NOTE

_If you don't need multiple and independent and linkable groups,_ _then I recommend using my simpler add-on ofxSurfingPresets._

Features

• Easy to integrate.
• Auto-generates a GUI to tweak all the parameters.
• GUI based on Dear ImGui.
• Clone, Copy, Swap, and Organize Presets.
• Handle Many Groups independently.
• Browse multi Groups and Presets by arrows keys.
• BPM Timed Randomizer Players to switch between presets independently for each group.
• Tweaking for probabilities and Short or Long time durations.
• Two Types of Presets
• Favorite: Fast clickable boxes/key-trigged presets.
• Standalone: Archived and named presets that we can load into and from favorites.
• Undo history engine.

</p> </details>

Usage

1. Set up your scene and initialize the related ofParameter's. 2. Add the parameters to the ofParameterGroup container. 3. Add the group to the add-on. 4. Set how many presets you want for the group, and what keys to associate as triggers. 5. Done! Just Play with the addon GUI

Examples

1_Basic (only one group)

Illustrates how to handle some ofParameter's bundled into one ofParameterGroup used as a container.



<details> <summary>CODE</summary> <p>

ofApp.h

``.c++

include "ofxPresetsManager.h"

ofxPresetsManager presetsManager;

ofParameterGroup params; ofParameter<int> shapeType; ofParameter<int> amount;

ofApp.cpp

.c++ ofApp::setup() { // Set the parameters // and add to the ofParameterGroup container. params.setName("sceneParamsGroup"); params.add(shapeType.set("shapeType", 1, 1, 2)); params.add(amount.set("amount", 10, 1, 24));

// Add the Group to the Preset Manager // Set the amount of Presets and each Key Trigger presetsManager.add(params, { 'a', 'b', '0', '1', '2', '3' }); presetsManager.setup(); }

ofApp::draw() { // Gui presetsManager.draw(); }

// Done! Nothing more!

</p>
</details>

2_MultiGroup

Helps to learn how to handle multiple ofParameterGroup's.



When adding individually multiple ofParameterGroup we can handle them independently.
We can use arrow keys to browse the Groups (up/down) and their Selectors (left/right).
Also, we will have an extra Global Selector called GROUP_LINK, which groups all the other group Selectors indexes:

<details>
  <summary>CODE</summary>
  <p>

.cpp // Group 0 presetsManager.add(params0, { 'q', 'w', 'e', 'r', 't' }); // Group 1 presetsManager.add(params1, { 'a', 's', 'd', 'f' }); // Group 2 presetsManager.add(params2, { 'z', 'x', 'c' }); // Group 3 presetsManager.add(params3, { 'b', 'n', 'm', ',', '.' });

presetsManager.setup(); `` </p> </details>

<details> <summary>ExamplesAdvanced</summary> <p>

3A_example-LinkServer and 3B_example-LinkClient:

Both examples run linked together using ofxRemoteParameters. This allows you to control the presets on the Client OF_App. The Server OF_App draws your scene using the linked/received parameters from the Client OF_App. This is useful because in some scenarios could help to improve the performance or the compiling time reducing dependencies. OUTDATED VIDEO </p> </details>

Dependencies

ofxImGui / _Fork from @Daandelange_ ofxSurfingHelpers ofxRemoteParameters / _Not required. For the examples 3A-3B_

Thanks

_Thanks to all the above add-ons coders!_ _Special Thanks 1 goes to Nicola Pisanti for the original https://github.com/npisanti/ofxGuiPresetSelector which inspired this add-on a lot. Some of his code is also used here._ _Special Thanks 2 goes to @Daandelange_ for his work to the DEFINITIVE ofxImGui repository. Thanks, Daan!

Tested Systems

• Windows10 / VS2017 / OF ~0.11+
• Should work on macOS too.

Author

An add-on by @moebiusSurfing ( ManuMolina ) 2019-2022

License

MIT License

<details> <summary>IDEAS / TODO</summary> <p>

A Better performant version without using hard disk files. Memory Mode, using a vector of XML/JSON instead of files. Improve (silent) de-serialization and ofParameter callbacks / triggering to improve speed. Add params tweening or filtering to ease transitions between presets when switching. Add a minimal/lite class to play compatible preset files but without any GUI or using a tiny ofxGui/ImGui version. More ideas noted into ofxPresetsManager.h. Feedback, Issues, PR's, and any kind of help are very welcome! </p> </details>
